SHUYI PDU can monitor power parameters such as power supply voltage, current, active power, reactive power, frequency, etc. in real time, which is convenient for users to master and manage various power equipment. When the system fails or the total load current exceeds the set value of the system, it will automatically alarm by SMS, email, telephone, etc. As a result, it can provide a safety and reliable power voltage for precision quipment, especially bitcoin mining machines.



Input type Input voltage range
AC single-phase, AC three-phase, DC 48v 100~277VAC/312VAC~418VAC/100VDC~240VDC/-43VDC~56VDC

Frequency Output rated voltage
50/60HZ 220VAC、250VAC、380VAC、-48VDC、240VDC

Installation method Operating temperature
Horizontal installation, vertical installation -10℃+75℃


Inquire Now
Product categories
how can we help you
You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.
Contact Us
New Products



Features
  • Data Center PDU

    High safety factor and cost saving

    The PDU management power supply has overload power-off protection and multiple circuit protection functions, which can prevent overload and high temperature, lightning strike, power surge and other hazards, and maximize the safety factor of the product. In addition, this product can help users realize unattended operation, save labor costs, and effectively reduce users' management and maintenance costs.



    Support remote control, convenient management

    The PDU can be connected to a local area network or the Internet. Users can remotely control the PDU through a computer to query, connect, disconnect or restart the power of the devices connected to each port, completely breaking the limit distance and area.



    Flexible policy management

    Users can customize the configuration strategy according to the usage of various electrical equipment. The product manages and monitors events according to the user's strategy, supports centralized management and automatic cycle control, manages multiple devices at the same time on one interface, and independently sets the switching cycle of the power supply, which is convenient and practical.

  •
Advantages
  •
  •

  •

    1.The PDU can be fixed and installed in a variety of ways, and its maintenance and removal are also very convenient;

    2. The PDU can automatically detect current and voltage, with an early warning function, which can prevent dangerous behaviors such as leakage and overload;

    3. The PDU is very safe and reliable, which can avoid frequent power failures, burns and other safety hazards due to poor contact and other reasons;

    4. The kit of the PDU is made of phosphorus copper material, which is fine in workmanship and durable;

    5. The PDU has PDU technology, high efficiency, anti-interference and strong performance, which can be used in the field of sensitive equipment such as computer room.





  •

  • 6.Intelligent PDUs include features that aid with data center management, such as metering and remote capabilities.

    7.Monitoring power consumption enables organizations to better gauge power usage. Devices can also remotely turn off outlets when not in use to save power.

    8.Remote toggle functions are available to control individual outlets.

    9.Intelligent PDUs can monitor energy use and provide data on where and how energy is consumed.



  •
Specifications



Input type AC single-phase, AC three-phase, DC 48v
Input voltage range 100~277VAC/312VAC~418VAC/100VDC~240VDC/-43VDC~56VDC
Frequency 50/60HZ
Output rated voltage 220VAC、250VAC、380VAC、-48VDC、240VDC
Installation method Horizontal installation, vertical installation
Operating temperature -10℃+75℃
Storage temperature -40℃+80℃
Relative humidity 5~90%（no condensation）
Working altitude Not more than 3000 meters
Output digits Maximum 48-bit output
Socket type：GB10A,GB16A,C13,C19,ENTA15,ENT20A,German standard, French standard, British standard, international five-hole, industrial socket, industrial terminal






Applications



Communication industry

Security system

IDC engine room

Electric power system

Track traffic

Enterprise small and medium data center

Office scene

dispatch center

Rack Smart PDU

 Micro Data Center PDU
