Rack Mounted Data Center Power Distribution Unit
Rack Mounted Data Center Power Distribution Unit
Rack Mounted Data Center Power Distribution Unit
Rack Mounted Data Center Power Distribution Unit

Rack Mounted Data Center Power Distribution Unit

The rack-mounted power distribution unit has both power distribution and management functions. Intelligent PDU can not only monitor parameters such as power supply voltage, power supply voltage frequency, and output current of each channel, but also realize remote control, centralized management, automatic cycle control, safety management, reliability management, etc. It is a good helper for power management.





Input type Input voltage range
AC single-phase, AC three-phase, DC 48v 100~277VAC/312VAC~418VAC/100VDC~240VDC/-43VDC~56VDC

Frequency Output rated voltage
50/60HZ 220VAC、250VAC、380VAC、-48VDC、240VDC

Installation method Operating temperature
Horizontal installation, vertical installation -10℃+75℃


Inquire Now
Product categories
how can we help you
You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.
Contact Us
New Products
Features
  • Data Center PDU

    Improved data center management
    Intelligent PDUs include features that aid with data center management, such as metering and remote capabilities.


    Reduced energy consumption
    Monitoring power consumption enables organizations to better gauge power usage. Devices can also remotely turn off outlets when not in use to save power


    Better control over power
    Remote toggle functions are available to control individual outlets.


    Energy consumption data
    Intelligent PDUs can monitor energy use and provide data on where and how energy is consumed.



  • Intelligent Power Distribution Unit

    Support remote control, easy to manage

    The PDU can be connected to the local area network or the Internet. Users can remotely control the PDU through a computer, and query, connect, disconnect or restart the power supply of each device connected to the port, which completely breaks the constraints of distance and region.



    Flexible policy management



    According to the usage of various electrical equipment, users can customize the configuration strategy. The product supports centralized management and automatic cycle control, manages several devices simultaneously in one interface.



Advantages



  • Integrated Data Center PDU

    High safety factor and cost saving

    The PDU management power supply has overload power-off protection and multiple circuit protection functions, which can prevent overload and high temperature, lightning strikes, power surges and other hazards, and maximize the safety factor of the product.



    Real-time power monitoring, automatic alarm protection

    PDU can monitor power parameters such as power supply voltage, current, active power, reactive power and frequency in real time, which is convenient for users to master and manage various power equipment.

  •
Specifications
Input type AC single-phase, AC three-phase, DC 48v
Input voltage range 100~277VAC/312VAC~418VAC/100VDC~240VDC/-43VDC~56VDC
Frequency 50/60HZ
Output rated voltage 220VAC、250VAC、380VAC、-48VDC、240VDC
Installation method Horizontal installation, vertical installation
Operating temperature -10℃+75℃
Storage temperature -40℃+80℃
Relative humidity 5~90%（no condensation）
Working altitude Not more than 3000 meters
Output digits Maximum 48-bit output
Socket type：GB10A,GB16A,C13,C19,ENTA15,ENT20A,German standard, French standard, British standard, international five-hole, industrial socket, industrial terminal




Applications





* Computer Room and Data Center (IDC)

* Switch room and mobile room

* Industrial Control Room

* Standard testing room and calibration center

* UPS and battery room
